PERFORMANCE
Processor
AMD Ryzen™ 7 7435HS (8C / 16T, 3.1 / 4.5GHz, 4MB L2 / 16MB L3)
Graphics
NVIDIA® GeForce RTX™ 4060 8GB GDDR6, Boost Clock 2370MHz, TGP 105W
Chipset
AMD SoC Platform
Memory
2x 12GB SO-DIMM DDR5-4800
Memory Slots
Two DDR5 SO-DIMM slots, dual-channel capable
Max Memory
Up to 32GB DDR5-4800
Storage
1TB SSD M.2 2242 PCIe® 4.0x4 NVMe®
Storage Support
Up to two drives, 2x M.2 SSD • M.2 2242 SSD up to 1TB
Storage Slot
Two M.2 2280 PCIe® 4.0 x4 slots
Card Reader
None
Optical
None
Audio Chip
High Definition (HD) Audio, Realtek® ALC3287 codec
Speakers
Stereo speakers, 2W x2, optimized with Nahimic Audio
Camera
HD 720p with E-shutter
Microphone
2x, Array
Battery
Integrated 60Wh
Power Adapter
170W Slim Tip (3-pin)
Special Features
AI Chip: LA1
DESIGN
Display
15.6" FHD (1920x1080) IPS 300nits Anti-glare, 100% sRGB, 144Hz, G-SYNC®
Touchscreen
None
Color Calibration
None
Keyboard
White Backlit, English
Touchpad
Buttonless Mylar® surface multi-touch touchpad, supports Precision TouchPad (PTP), 75 x 120 mm (2.95 x 4.72 inches)
Case Color
Luna Grey
Surface Treatment
Painting
Case Material
PC-ABS (Top), PC-ABS (Bottom)
Dimensions (WxDxH)
359.86 x 258.7 x 21.9-23.9 mm (14.17 x 10.19 x 0.86-0.94 inches)
Weight
Starting at 2.38 kg (5.25 lbs)
SOFTWARE
Operating System
None
Bundled Software
None
CONNECTIVITY
Ethernet
100/1000M (RJ-45)
WLAN + Bluetooth
Wi-Fi® 6, 802.11ax 2x2 + BT5.2
Standard Ports
3x USB-A (USB 5Gbps / USB 3.2 Gen 1)
1x USB-C® (USB 10Gbps / USB 3.2 Gen 2), with Lenovo® PD 140W and DisplayPort™ 1.4
1x HDMI® 2.1, up to 8K/60Hz
1x Headphone / microphone combo jack (3.5mm)
1x Ethernet (RJ-45)
1x Power connector
Docking
Various docking solutions supported via USB-C®. For more compatible docking solutions, please visit Docking for LOQ 15ARP9
SECURITY & PRIVACY
Security Chip
Firmware TPM 2.0 Enabled
Fingerprint Reader
None
Other Security
E-shutter
